Industrial Ethernet Switches
Eight gigabit ports that power what they connect — cameras, wireless AP and access control on one cable each. The same board as the LBTD08G, with the PoE module fitted at the works.
Supply under your own brand, from 1 unit. Printed label samples the same day. See OEM & private label options →
Overview
The LBTD08GP is the eight-port member of the LBTD gigabit DIN-rail family with PoE fitted at the works. Every copper port delivers PoE+ (IEEE 802.3af/at) alongside the data, so an IP camera, a wireless access point or a door controller needs one cable instead of two — and the cabinet needs no separate injector or mid-span.
Electrically it is the same platform as the rest of the family: two independent power inputs run in redundancy, the power stage withstands a 5000 A (8/20 μs) surge, and the metal IP40 housing dissipates heat without a fan. There is no air filter to service and no moving part to seize up on a pole or in a tunnel cabinet.
The board is identical to the non-PoE LBTD08G — the P-suffix model is the same switch with the PoE module fitted. If you stock both, one spare board covers two order codes, and the 5-year warranty applies to the whole line rather than to a promotion window.
PoE+ (802.3af/at) on all eight copper ports. The powered device negotiates up to 30 W — no configuration, no per-port switches.
The P-suffix model is the LBTD08G with the PoE module fitted. Identical mechanics and mounting.
Dual redundant DC 12–52 V inputs, 5000 A surge headroom, IP40 metal housing, −40 to +80 °C, MTBF 300,000 h.
Printed label samples the same day, from one unit. Colour labels, silk printing and retail packaging at volume.
Specifications
Three groups, same order on every switch page: ports, PoE and switching first, power and protection second, mechanical and environmental third.
Need a parameter that is not listed here? The full EMC immunity table, per-port PoE detail and the packaging data are in the detailed specifications below. You can also ask us for the datasheet by email or request a quote.
Detailed specifications
The long-tail data — EMC immunity, physical details and reliability figures. Filled in by our technical team on the product record, so it can be completed without touching the sections above.
PoE & power budget
An eight-port PoE switch is chosen on two numbers: what each port can negotiate, and what the whole unit can supply. Both are answered here before you size the cabinet supply.
Every PoE model in this family supports IEEE 802.3af and 802.3at simultaneously — there is no separate "af-only" version. Camera, radio or door controller, the port negotiates up to 30 W with the powered device without any configuration on the switch.
LBTD05GP PoE version of LBTD05G5 × 10/100/1000 Mbps, DIN rail, same wide-range dual power inputs. Ports 1–5 deliver PoE/PoE+ for cameras and radios. Open LBTD05GP →
LBTD08GP This page8 × 10/100/1000 Mbps, DIN rail, same wide-range dual power inputs. All eight ports deliver PoE/PoE+ for cameras, wireless AP and access control.
Port standard ≠ whole-unit budget. 802.3at is what each port can negotiate (up to 30 W). The total power budget depends on the model and its PoE power module — the budget figure for your configuration is confirmed with the quotation, so you can size the power supply before you order.
Family & ordering
The model name is the order code — there is nothing to assemble. Read the segments below to decode any model in the family, and pick the one that matches your port count and power plan.
05 5 ports08 8 ports016 16 portsG GigabitP PoE fitted(no P)| Model | Copper ports | PoE | Pair model |
|---|---|---|---|
LBTD05GCompact DIN-rail housing | 5 × 10/100/1000 Mbps | Without PoE | PoE version: LBTD05GP |
LBTD05GPPoE module fitted at the works | 5 × 10/100/1000 Mbps | PoE+ (802.3af/at) | Without PoE: LBTD05G |
LBTD08GCompact DIN-rail housing | 8 × 10/100/1000 Mbps | Without PoE | PoE version: LBTD08GP |
LBTD08GPThis page · PoE module fitted at the works | 8 × 10/100/1000 Mbps | PoE+ (802.3af/at) | Without PoE: LBTD08G |
LBTD016GFull-width DIN housing | 16 × 10/100/1000 Mbps | Without PoE | 16-port PoE: ask us |
Quote the full model name — for example LBTD08GP — and we will come back with availability, lead time and pricing. The switch series carries a 5-year warranty across every model in the table.
Accessories
Field spares and bench supplies with the matching Phoenix-type output. Order alongside the switch — they ship in the same carton.
12 V / 2 A DC adapter — for cabinets fed from a 12 V rail or bench testing.
24 V / 1 A DC adapter — the most common match for 24 V control panels.
48 V / 1 A DC adapter — for 48 V plant supply or PoE-adjacent cabinets.
Applications
Typical uses reported by distributors and system integrators working with this model.
Eight cameras on eight cables with PoE+ — no injectors, no mid-spans, no extra power strip in the cabinet.
Powers the APs and carries their uplink on the same port, in one 8-port footprint.
Door controllers and readers fed over PoE on the same switch as the camera they work with.
One switch for cameras, AP, POS and the uplink router where rack space is at a premium.
−40 °C start-up, sealed IP40 housing and no fan to service on a pole or in a tunnel cabinet.
A single PoE switch across the machine range; private label from one unit puts your brand on the housing.
Downloads
The datasheet and the compliance documents for this model are sent by email on request — usually the same working day. User manuals and firmware are released after a short form, so we can keep track of which hardware revision you are running.
Full parameter table, PoE detail, EMC immunity data, accessories and ordering information.
The certificate and declaration set that applies to this model — for your own certification file.
Installation, wiring and LED reference for this hardware revision, released after a short form.
Looking for something else for this model? All documents for the LBTD08GP →
Type approval is the responsibility of the brand owner. Certification cost is not included in the quoted price. We supply the test reports and engineering support you need — talk to us before you start the process.
