Industrial Routers
An 83 mm 4G router that fits where full-size units don't: two Ethernet ports, 2.4 GHz Wi-Fi and an optional RS-485 port in a 153 g metal shell rated from −40 °C to +80 °C.
Supply under your own brand, from 1 unit. Printed label samples the same day. See OEM & private label options →
Overview
The T300-260S is the smallest router in the T300 family: 83 × 66 × 26 mm and 153 g — genuinely palm-sized. It carries the same 4G Cat-4 platform as the volume models, so a tight enclosure no longer means a weaker uplink.
The interface set is deliberately lean: two 10/100 Mbps ports (LAN1 is WAN/LAN adaptive) and 2.4 GHz Wi-Fi for commissioning. Where a serial link is needed, an RS-485 port — RS-232 on request — is fitted to order, so the board inside stays the same and the quote matches the project.
The wide −40 °C to +80 °C operating range is unusual at this size and lets the 260S ride in outdoor cabinets, vehicles and unheated equipment. The DC 12–35 V input carries surge, over-voltage and reverse-polarity protection as built. Configuration, branding and final inspection stay with our own team on every order.
83 × 66 × 26 mm and 153 g — mounts where a full-size router physically will not go.
Wide-temperature rating at palm size — outdoor cabinets, vehicles and rooftops without a heater.
RS-485 fitted to order (RS-232 on request) — one board, quotes matched to the project.
Printed label samples the same day, from one unit. Enclosure silk printing and retail packaging at volume.
Specifications
Three groups, same order on every router page: cellular and wireless first, interfaces and power second, mechanical and environmental third.
Need a parameter that is not listed here? The full band table per regional version, EMC data and the packaging list are in the detailed specifications below. You can also download the full datasheet (PDF) or request a quote.
Detailed specifications
The long-tail data — network functions, physical details and reliability figures. Filled in by our technical team on the product record, so it can be completed without touching the sections above.
Family & ordering
The model name is the order code — there is nothing to assemble. Read the segments below to decode any model in the family, and pick the one that matches your network and your interfaces.
260S 4GPRO1 5G1800 4GCN / EA / AUNA / SA / JP / GL| Model | Network | Wi-Fi | In this family |
|---|---|---|---|
T300-260SThis page · 4G Cat-4 | 2 × 100 Mbps · RS-485 optional | 2.4 GHz | |
T300-PRO15G Sub-6 | 4 × gigabit + serial | Dual band 2.4 / 5.8 GHz | |
T300-18004G Cat-4 | Multiple 100 Mbps ports | 2.4 GHz | |
T300Base model | Entry configuration | Options on request |
Quote the full model name — for example T300-260S — and we will come back with availability, lead time and pricing. See all 182 orderable router models →
Regional versions
4G band plans differ by market. Send the destination country and we will quote the matching regional version — this is the first question most distributors ask.
Band plans for Europe, Asia, Africa and Australia — the mainstream 4G networks.
North and South American band plans, including the 600 MHz and AWS combinations.
Japan- and global-version band plans for networks outside the mainstream groups.
Applications
Typical uses reported by distributors and system integrators working with this model.
Optional RS-485 reads the meter directly; the router forwards the readings over 4G — no separate converter in the cabinet.
83 × 66 × 26 mm fits inside the machine or the distribution box — the uplink moves in with the equipment.
−40 °C to +80 °C operation and a 12–35 V input tolerate engine bays and cold-chain fleets.
Under 400 mA power draw and a wide 12–35 V input for sites fed from a DC bus.
Wi-Fi for commissioning, 4G for the backhaul — and a footprint that leaves the DIN rail to the breakers.
The model distributors reorder most often — component stock covers 1–2 months of demand.
Downloads
The datasheet and the compliance documents for this model open straight away — no form, no account. User manuals and firmware are released after a short form, so we can keep track of which hardware revision you are running.
Full parameter table, band sets per regional version, EMC data, accessory list and ordering information.
The certificate and declaration set that applies to this model — for your own certification file.
Installation, configuration and firmware for this hardware revision, released after a short form.
Looking for something else for this model? All documents for the T300-260S →
Type approval is the responsibility of the brand owner. Certification cost is not included in the quoted price. We supply the test reports and engineering support you need — talk to us before you start the process.
Keep looking
Get in touch
Tell us the destination market and the interfaces you need, and we will come back with the matching regional version, availability, lead time and pricing. Datasheet included with every quote.
Your enquiry goes to the technical team, not a call centre. Expect a parameter-level answer.
Pricing, lead time, MOQ and the current document set come back in one message.
