Point-to-point and point-to-multipoint links from 1 km to 30 km, in 2.4 GHz and 5.8 GHz, with IP65 / IP67 outdoor housings and built-in directional antennas. Used for building-to-building backhaul, CCTV backhaul, elevator shafts, farms and industrial sites where trenching fiber is not an option. Supplied as a white-label platform — your brand, your packaging, from one unit.
Most of our bridges use non-standard passive PoE. They must be powered by the injector supplied with the unit — connecting them to a standard 802.3af/at switch will damage the device.
Options show only the values that exist in this category. Every model ships with its matching PoE injector — check the voltage before you connect anything else.
2 km multipoint bridge with DIP-switch pairing
24 V passive PoE (non-standard) — use the supplied injector, do not connect to a standard PoE switch.
13 km outdoor link with IP67 housing
24 V passive PoE (non-standard) — use the supplied injector. A 48 V version can be built to order.
30 km dish link, the only standard-PoE model in the range
Standard 802.3af (48 V) — can be powered from a normal PoE switch. DC 12–24 V input also supported.
Mini 2.4 GHz bridge for elevator shafts and short hops
24 V passive PoE (non-standard) — use the supplied injector.
2 km 5.8 GHz bridge, 1-to-8 multipoint
24 V passive PoE (non-standard) — use the supplied injector.
5 km TDMA bridge with remote management
24 V passive PoE (non-standard) — use the supplied injector.
5 km Gigabit bridge, IP67
12 V passive PoE (non-standard) — use the supplied injector; DC 12 V jack also available.
5 km outdoor bridge, 48 V version on request
24 V passive PoE (non-standard) — use the supplied injector. A 48 V version can be built to order.
1. Check the PoE voltage before you order. Seven of our eight bridges run on non-standard passive PoE (24 V or 12 V) and are powered by the injector in the box. If you plan to power them from an existing PoE switch, tell us before ordering — we can build a 48 V version on request. 2. Type approval is the responsibility of the brand owner. These are OEM platforms; radio approvals, certification cost and local registrations are not included in the quoted price. 3. Private label starts at one unit. A printed label ships the same day; silkscreen and laser marking start at CNY 500 for the plate, refundable against your first bulk order.
